Wire Mesh Fence Double Gate Green Pvc Coated Europe Economy Garden Gate With Safty Lock Round Post
Introduction:
The panel is welded different, with two horizontal wires. It en:able the fence much stronge.
Widely used in highways,railways,airports,bridges,parks,etc.
Double Fence Gate Size
| Width | Height | Frame pipe | Post size | Mesh inside | Tube inside | ||||
| size | Thickness | Size | Thickness | Wire Dia. | Hole size | Pipe size | Distance | ||
|
2.0m 3.0m 4.0m 6.0m 8.0m |
1m 1.2m 1.5m 1.8m 2m 2.2m 2.4m |
60*60mm |
2.5mm |
60x60mm 80x80mm 100x100mm |
1.8mm 2mm 2.5mm 3mm |
4mm 5mm 6mm |
50x100mm 50x200mm 75x150mm 75x200mm 10Ox200mm |
20x20mm 20x30mm |
100mm 120mm 140mm |
| Surface treatment | 1.Hot-dipped galvanized after black wire and tube welded 2.Powder coated aftergalvanized wire and tube welded |
||||||||
Gate Classify
1. Weaving Fence Gate
Material : Low carbon steel wire , Galvanized wire, PVC Coated Wire, PE wire
Wire diameter : 1.5mm---5.0mm
Opening: 40*40mm;50*50mm;60*60mm
Double Swing and Single swing
Gate Frame : OD25mm; OD32mm; OD48mm;
Gate Post : OD60mm; OD75mm
2. Welded Fence Gate
Wire diameter : 2.5mm--6.0mm
Opening: 50*100mm;50*150mm;50*200mm; 75*150mm;75*200mm
Double Swing and Single Swing
Gate Frame : 40*60mm
Gate Post: 60*60mm
Surface treatment : Galvanized or PVC Coated
Surface Treatment:
Electric Gal.: 40~60g/sq. M.
Hot dipped Gal.: 40~500g/sq. M.
Powders spread coating: 160~240 microns
PVC/PE dipped coating: 600~1000 microns
Common Colors:
Moss green (RAL6005),
Pure white (RAL9010),
Stone grey (RAL7030),
Traffic red (RAL3020),
Traffic yellow (RAL1023), and Traffic blue (RAL5017).
Besides, other RAL color required can be delivered to us.
