Decorative Wire Mesh Fence Double Gate Pvc Coated Garden Gate
Home And Garden Gates Introduction
Home And Garden Gates Made of galvanized circular or square galvanized tube with welded panel inner hot dipped galvanized, outer powder coated.The color can be as per the customer's selection. Complete shrink packing for the DIY assembly.Other size maybe available upon request.
Home And Garden Gates Specification
Panel Specifications
| Width | Height | Frame pipe | Post size | Mesh inside | Tube inside | ||||
| size | Thickness | Size | Thickness | Wire Dia. | Hole size | Pipe size | Distance | ||
| 2m 3m 4m 6m 8m |
1m 1.2m 1.5m 1.8m 2m 2.2m 2.4m |
40*60mm 50*50mm 60*60mm 60x80mm |
1.5mm 2.0mm 2.5mm |
60x60mm 80x80mm 100x100mm |
1.8mm 2.0mm 2.5mm 3.0mm |
4mm 5mm 6mm |
50x100mm 50x200mm 75x150mm 75x200mm 10Ox200mm |
20x20mm 20x30mm |
100mm 120mm 140mm |
| Surface treatment | 1.Hot-dipped galvanized after black wire and tube welded 2.Powder coated aftergalvanized wire and tube welded |
||||||||
Home And Garden Gates Feature and Benefits
· Aesthetically pleasing
· Rust and corrosion proof powder coat finish
· Variety of powder coat finish colours
· Prevents unauthorised access of vehicles and persons
How to install it?
1)When installing your fence gate, leave adequate space between two of your posts for a gate.
2) Attach the hinges to your gate, one near the gate's top and one near the bottom (just like the hinges on a door).
Hold the gate in the spacing between your posts. Please some scrap blocks of wood under the gate
3) With your gate in place, use a power drill to screw the hinges into your fence post.
4)Your latch should be separated into two pieces: a more a complex catching mechanism and a simple hook
5) Situate the hook on your gate, and align it with the catching mechanism. Use your power drill to screw the hook into the gate
Packaging & Delivery
packed in wooden pallet,metal pallet
