| Place of Origin: | CHINA |
| Brand Name: | BD Fence |
| Certification: | ISO9001,CE |
| Model Number: | GF085 |
Double wire mesh fence also called twin wire mesh fence is extremely strong and rigid mesh fence system with a special structure - double horizontal wire welded to single vertical wire - more endurable and stable than common fence. In other words, double wire fence panel has double horizontal large diameter rods attached on both sides of the panel.
Technical characteristics
Wire diameter: 5/4/5 or 6/5/6 or 8/6/8 mm.
Mesh Size: 50 × 200 mm.
Fence height: 1.23–2.43 m.
Surface treatment: Fence galvanized and coated with a polymeric composition coating does not fade in the sun and can withstand extremes of temperature. The electro galvanized level 20gram/square meter and hot dipped galvanized double mesh fence zinc level is 60gram-600gram/square meter.
Color: green RAL 6005 or grey, white.
Post section: 40*60*2mm or 60 × 60 × 2 mm or 80 × 80 × 2 mm.
Mounting: clip or bracket with a through bolt.
| Double wire mesh fence | |||||
|
Panel Height x Width mm |
Mesh Size mm |
Wire diameter | Post Height | ||
|
Wire dia mm |
Wire dia mm |
Wire dia mm |
|||
| 630 x 2500 | 50 x 200 | 8x2 + 6 | 6x2 + 5 | 6x2 + 4 | 1100 |
| 830 x 2500 | 50 x 200 | 8x2 + 6 | 6x2 + 5 | 6x2 + 4 | 1300 |
| 1030 x 2500 | 50 x 200 | 8x2 + 6 | 6x2 + 5 | 6x2 + 4 | 1500 |
| 1230 x 2500 | 50 x 200 | 8x2 + 6 | 6x2 + 5 | 6x2 + 4 | 1700 |
| 1430 x 2500 | 50 x 200 | 8x2 + 6 | 6x2 + 5 | 6x2 + 4 | 1900 |
| 1630 x 2500 | 50 x 200 | 8x2 + 6 | 6x2 + 5 | 6x2 + 4 | 2100 |
| 1830 x 2500 | 50 x 200 | 8x2 + 6 | 6x2 + 5 | 6x2 + 4 | 2400 |
| 2030 x 2500 | 50 x 200 | 8x2 + 6 | 6x2 + 5 | 6x2 + 4 | 2600 |
| 2230 x 2500 | 50 x 200 | 8x2 + 6 | 6x2 + 5 | 6x2 + 4 | 2800 |
| 2430 x 2500 | 50 x 200 | 8x2 + 6 | 6x2 + 5 | 6x2 + 4 | 3000 |
Hebei Bending Fence Technology Co.,Ltd was founded in 1992 as a manufacturer of wide variety metal fences. We engaged in the production, research, development, sales, and services of metal fences, gates, and barriers.
BD FENCE spent more than 3 decades of experience providing fencing solutions, we gain enough knowledge on how to produce top-quality fencing which led us to become a trusted supplier & exporter globally.
As one of the manufacturing pioneers in metal fencing solutions. We also accept customizing metal fences with excellent quality. With professional experience in the metal fence business, our skilled staff members are able to provide the highest level of support, including drafting and engineering of our products. In order to meet our clients’ project requirements.
FAQ
1.Are you a factory?
Answer:yes,we are a factory that manufactured fence for 32 years.
2.Can you send the cargo to seaport? Where is your nearest sea port?
Answer:yes, sure ,our nearest seaport is Xingang Port.
3.How about the height fence?
Answer:The height is about 2m, but we accept all customized size,you can let us know the height and the length, then we can make design and calculate the prices.
4.Can I have more details of the fence, such as real picture and the accessories?
Answer: yes, sure, please contact us,we will send you drawing and the details parts pictures.
5.Can you make the color according to our request?
Answer: yes,we can ,the common color is Green,Yellow,White,Gray. More Questions If you have more question, please contact us for best service Contact Now
6.How long does it take to produce?
3 to 4 weeks is the delivery time range depending on the model and quantity of the fence.
7.Do I need to hire a professional installer for my metal fence?
All of our metal fences are very easy to install. Aside from its easy installation, we also provide an installation guide. That’s why you can even install it by yourself.
