Main Features
| Material | galvanized pipe |
| Size (H*L) | 1.8*2.1m;1.8*2.07m |
| horizontal pipe |
three types( round,square,oval) 1) round pipe:32*1.6mm;42*1.6mm 2) square pipe:40*40*1.6mm;50*50*1.6mm 3) oval pipe:30*60*1.6mm;40*80*1.6mm |
| structural style | one set=one net+two pins |
| bars/rails | 1.8m high with 6 bars/rails or 1.6m high with 5 bars/rails |
| applications | Used in protecting of animals |
| main markets | Australia,New Zealand,Canada,US,European countries and Asia countries |
| Product Name | Portable Livestock Cattle panels |
| Product Material | Hot-dip galvanized Steel Round Pipe or Square Tube, Oval Tubes |
| Dimensions | these panels are 2.1x1.8mtr, 2.4x1.8mtr, or others size. |
| Pipe Posts Material | 40x40mm, 50x50mm |
| Pipe thickness | 1.5mm, 1.6mm, 2.0mm, 2.5mm thick etc |
| Rails | 3/5/6/7/9rails |
| Connecting | Round pipe lugs & Drop pins |
| Welding | Fully welded post brackets |
| Finish | Glavnaized or Powder coating |
]1. Portable: easy fast to handle (set up, remove and put down), makes the fence panel very flexible.
2. Robust: interlocking system makes the fence very stable; quality steel and fully welding makes the panel more stronger; heavy duty and anti-broken; high zinc or PVC coated make the fence durable.
3.Environment Protection: connection with welded to bracket lugs and joining pins, no need to dig holes or lay foundations. And it benefit grassland protection.
4.Livestock Protection: no sharp edge, very smooth welding spot finish.
5.Cost-effective: give your corral years of service and minimal maintenance at a low initial cost.
Style1 : Round style livestock panels
| material | pre hot dipped galvanized steel pipe |
| finishing(zinc coating) | mor than 15 microns |
| HeightxLength | 1800mm x 2100mm |
| vertical pipe |
32mm O.D x1.6mm thickness 42mm O.D x 1.6 mm thickness |
| horizontal rails |
32mm O.D x1.6mm thickness 42mm O.D X 1.6mm thck (6 round rails) |
| Welding | Fully welded post brackets |
| welds | bull bars are fully welded, each weld is protected with epoxy paint |
Australia cattle farm equipment / cattle panels
| material | pre hot dipped galvanized steel pipe |
| finishing(zinc coating) | more than 15 microns |
| HeightxLength | 1800mm x 2100mm |
| Vertical pipe |
50 x 50mm RHS x 1.6mm thickness 40 x 40mm RHS x 1.6 mm thicknss |
| Horizontal rails |
30x60mm oval rail x 1.6mm thickness 40x80mm oval rail x 1.6mm thickness 40x120mm oval rail x 1.6mm thickness (6 oval rails) |
| Welding | Fully welded post brackets |
| welds |
bull bars are fully welded, each weld is protected with epoxy paint |
| material | pre hot dipped galvanized steel pipe |
| finishing(zinc coating) | mor than 15 microns |
| HeightxLength | 1800mm x 2100mm |
| vertical pipe |
50 x 50mm RHS x 1.6mm thickness 40 x 40mm RHS x 1.6mm thickness |
| horizontal rails |
50 x 50mm RHS x 1.6mm thickness 40 x 40mm RHS x 1.6mm thickness (6 square rails) |
| Welding | Fully welded post brackets |
| welds |
bull bars are fully welded, each weld is protected with epoxy paint |
FAQ
Q1. What is the advantage about your company?
A1. Our company has professional team and professional production line.
Q2. Why should I choose your products?
A2. We use our many years of experience to ensure that we provide our customers with the best quality. We are also continuously
improving quality control system.
Q3. The logo and the color can be customized?
A3. Yes, we welcome you to sample custom.
Q4. Any other good service your company can provide?
A4. We take the most care in our products and service with integrity and honesty. When you need help, we are always standby your
