--with welded top caps and foot plates, water and dust proof
--welded lugs for easy connection. The lugs are welded for all four sides, very durable and safe.
--footplate on the panel,can cement the panels on the ground by nails.
--2xjoining pins are supplied for each panel
-- Easily assembled & disassembled
2. cheap high tensile galvanised steel cattle farm panel for sale
The popular specification:
| No. of Rails | Available in 3, 4, 5 or 6 Rails |
| Height x Length | 1.8mx2.1m, 1.6x2.1m, 1.8mx2.4m and so on |
| pole style | Round pipe or square tube or oval tube |
| Pole specification |
32mmO.D, 40mmO.D, RHS40mm, RHS50mm and so on |
| Material | galvanized pipe |
| Size (H*L) | 1.8*2.1m;1.8*2.07m |
| horizontal pipe | three types( round,square,oval) 1) round pipe:32*1.6mm;42*1.6mm 2) square pipe:40*40*1.6mm;50*50*1.6mm 3) oval pipe:30*60*1.6mm;40*80*1.6mm |
| structural style | one set=one net+two pins |
| bars/rails | 1.8m high with 6 bars/rails or 1.6m high with 5 bars/rails |
| applications | Used in protecting of animals |
| main markets | Australia,New Zealand,Canada,US,European countries and Asia countries |
| Standard specification | Normal size |
| Height x Length | 2.9mX1.05m,2.1mX1.26m,2.2mX1.26m and so on |
| Pole style | Round pipe or square tube or oval tube |
| Pole specification | 32mmO. D, 42mmO. D, RHS40mm, RHS50mm and so on |
| Package details | In steel pallet or in bulk |
Style1 : Round style livestock panels
| material | pre hot dipped galvanized steel pipe |
| finishing(zinc coating) | mor than 15 microns |
| HeightxLength | 1800mm x 2100mm |
| vertical pipe |
32mm O.D x1.6mm thickness 42mm O.D x 1.6 mm thickness |
| horizontal rails |
32mm O.D x1.6mm thickness 42mm O.D X 1.6mm thck (6 round rails) |
| Welding | Fully welded post brackets |
| welds | bull bars are fully welded, each weld is protected with epoxy paint |
Australia cattle farm equipment / cattle panels
| material | pre hot dipped galvanized steel pipe |
| finishing(zinc coating) | more than 15 microns |
| HeightxLength | 1800mm x 2100mm |
| Vertical pipe |
50 x 50mm RHS x 1.6mm thickness 40 x 40mm RHS x 1.6 mm thicknss |
| Horizontal rails |
30x60mm oval rail x 1.6mm thickness 40x80mm oval rail x 1.6mm thickness 40x120mm oval rail x 1.6mm thickness (6 oval rails) |
| Welding | Fully welded post brackets |
| welds |
bull bars are fully welded, each weld is protected with epoxy paint |
| material | pre hot dipped galvanized steel pipe |
| finishing(zinc coating) | mor than 15 microns |
| HeightxLength | 1800mm x 2100mm |
| vertical pipe |
50 x 50mm RHS x 1.6mm thickness 40 x 40mm RHS x 1.6mm thickness |
| horizontal rails |
50 x 50mm RHS x 1.6mm thickness 40 x 40mm RHS x 1.6mm thickness (6 square rails) |
| Welding | Fully welded post brackets |
| welds |
bull bars are fully welded, each weld is protected with epoxy paint |
