| H x L | 1.8x2.1m, 1.6x2.1m, 1.7x2.1m, 1.3x2.9m, etc |
| Pipe Style | Round pipe, square pipe or oval pipe |
|
Pipe Size |
Round: 32mm, 40mm, O.D etc. Square: 40x40mm, 50x50mm, RHS etc. Oval: 30x60mm, 40x80mm |
| Finish | Hot-dipped galvanized, power coating |
| Product Name | Corral Panel |
| Materials | Carbon steel |
| Corrosion Form | hot-dipped galvanized or paint |
| Material | Steel |
| Features | It can quickly and easily be installed, without the need to disturb the surface area by digging holes or laying foundations. |
| Surface treatment | Hot Dipped Galvanized/ Electric Galvanized + Polyester Powder Coated |
| Description | -1.8m high with 6 bars/rails or 1.6m high with 5 bars/rails. -Complete with Caps & Foot plates. -Holes for ground pin on one leg of each panel. -Elongated lug holes in brackets, for ease when connecting. |
| Height x Length | 1.8m * 2.1m, 1.6 * 2.1m, 1.8m * 2.4m and so on custom |
| Pipen thckness | 0.8mm-3mm |
| Round pipe | 32mm,38mm,42mm,48mm,60mm |
| Square pipe | 40mm*40mm 50mm*50mm,60mm*60mm,etc |
| Oval pipe | 30mm*60mm 40mm*80mm 50mm*100mm |
| pole style | Round pipe or square tube or oval tube |
| Package details | In steel pallet or in bulk |
| Applications | breeding and grazing sheep, goats, mutton,lamb. And very convenient for rotation |
| Customization | please feel free to contact us if have custom requirements |
Style1 : Round style livestock panels
| material | pre hot dipped galvanized steel pipe |
| finishing(zinc coating) | mor than 15 microns |
| HeightxLength | 1800mm x 2100mm |
| vertical pipe |
32mm O.D x1.6mm thickness 42mm O.D x 1.6 mm thickness |
| horizontal rails |
32mm O.D x1.6mm thickness 42mm O.D X 1.6mm thck (6 round rails) |
| Welding | Fully welded post brackets |
| welds | bull bars are fully welded, each weld is protected with epoxy paint |
Australia cattle farm equipment / cattle panels
| material | pre hot dipped galvanized steel pipe |
| finishing(zinc coating) | more than 15 microns |
| HeightxLength | 1800mm x 2100mm |
| Vertical pipe |
50 x 50mm RHS x 1.6mm thickness 40 x 40mm RHS x 1.6 mm thicknss |
| Horizontal rails |
30x60mm oval rail x 1.6mm thickness 40x80mm oval rail x 1.6mm thickness 40x120mm oval rail x 1.6mm thickness (6 oval rails) |
| Welding | Fully welded post brackets |
| welds |
bull bars are fully welded, each weld is protected with epoxy paint |
| material | pre hot dipped galvanized steel pipe |
| finishing(zinc coating) | mor than 15 microns |
| HeightxLength | 1800mm x 2100mm |
| vertical pipe |
50 x 50mm RHS x 1.6mm thickness 40 x 40mm RHS x 1.6mm thickness |
| horizontal rails |
50 x 50mm RHS x 1.6mm thickness 40 x 40mm RHS x 1.6mm thickness (6 square rails) |
| Welding | Fully welded post brackets |
| welds |
bull bars are fully welded, each weld is protected with epoxy paint |
