| Place of Origin: | China |
| Brand Name: | BD Fence |
| Certification: | ISO14001:2015/OHSAS 18001:2007/ ISO9001:2015 |
| Model Number: | GF085-2 |
Twin Wire Steel Meshes Steel Fence 6/5/6 Double Wire special design fence
Double Wire special design fence Details
Double wire welded mesh fence is welded with one vertical wire and two horizontal wires; according to wire thickness, the fence can be divided into 6/5/6 type and 8/6/8 type. This can be strong enough, compared to the normal welded fence panel.
Our double wire fence is made of Q195 or Q235 low carbon steel wire material, and the surface treatment is galvanized, powder coated or PVC coated, according to customer's request. The brand of powder we use is Akzo Nobel or Dupont.
Advantage:
1. Vandal resistant, Low maintenance
2. Strong and reliable security
3. Simple structure, Attractive appearance
4. Easy installation, Convenient transport
Application: Fencing and protection for road, railway, airport, residence district, seaport, garden, feeding and husbandry.
Double Wire special design fence Specifications:
| Wire Diameter | Mesh Size | Panel Height(mm) | Panel Width(mm) | Post Height(mm) | Post Size |
|
8/6/8mm 6/5/6mm |
200*50mm | 630 | 2500 | 1100 |
40*40*1.5mm 40*60*2mm 60*60*2mm 80*80*2mm |
| 830 | 2500 | 1300 | |||
| 1030 | 2500 | 1500 | |||
| 1230 | 2500 | 1700 | |||
| 1430 | 2500 | 1900 | |||
| 1630 | 2500 | 2100 | |||
| 1830 | 2500/3000 | 2400 | |||
| 2030 | 2500/3000 | 2600 | |||
| 2230 | 2500/3000 | 2800 | |||
| 2430 | 2500/3000 | 3000 | |||
| Material | Low carbon steel wire,Galvanized wire,etc. | ||||
| Surface treatment | Hot dip galvanized,Powder coated,etc. | ||||
