| Place of Origin: | Hebei, China |
| Brand Name: | Giant Fence |
| Certification: | ISO14001:2015/OHSAS 18001:2007/ ISO9001:2015 |
| Model Number: | GF070 |
Galvanized Tube Powder Coated Steel Metal Fence Black Steel Fence
Tubular Fence Brief Introduction
Galvanized Steel Picket Fence can be zinc galvanized picket fence or powder coated steel fence. The panels are manufactured with strong steel pickets and rails available in a wide range of sizes and styles. Steel Tube / Bar Panels are attached with high-strength steel or aluminum brackets to galvanised square tubular steel or aluminum posts. The Spear top design of this tubular fence creates an aesthetically pleasing fence which at the same time deters intruders. This security level ornamental fence is suitable for gardens, residential, industrial and commercial properties, schools, pools and boundary fencing.
Tubular Fence Specification
| Panel length | 1.5m | 1.8m | 2.0m | 2.4m | 2.5m | 3.0m |
| Panel height | 1200mm | 1500mm | 1800mm | 2000mm | 2100mm | 2400mm |
| Rails | 25*25mm | 40*40mm | 45*45mm | |||
| Rails No | 2pcs | 3pcs | 4pcs | |||
| Rails thickness | 1.0mm | 1.2mm | 1.5mm | 1.8mm | 2.0mm | 2.5mm |
|
picket |
16*16*1mm/1.2mm | 19*19*1.2mm/1.5mm | 16*1.2mm/1.5mm | 19*1.2mm/1.5mm | ||
| Picket distance | 100mm | 125mm | 140mm | |||
|
post size |
50*50*1.5/1.8/2mm | 60*60*1.5/1.8/2mm | 75*75*1.5/1.8/2mm | |||
| Colors | Black ral 9005 | Grey ral 7016 | White ral9010 | Blueral5012 | ||
| features | Easily Assembled | Eco Friendly | Waterproof | Rot Proof | Rodent Proof | |
| packaging | Wrapped with plastic film. | Covered with carton board. | Tie with steel belt. | Covered with Your logo. | Loaded on steel pallet | |
| Surface treatment |
Surface treatment:powder coated after hot -dipped galvanized tube welded |
|||||
Tubular Steel Fence Application
