Australia Standard Building Removable Event Fence Panel Construction Site Mobile Temporary Fence
Temporary Fence Introduction
Building fence also called portable fence & removable fence.Easy to handle;Sample,one-person installation;Easy transportation.It
is widely used for Security,Construction,Crowd control and civil projects,etc.
Designed to add extra stability to the fence these temporary fence stays are for use in areas where high winds are likely or when something has been added to the fence system that will increase wind resistance. Each stay should be supported with three bases and clamped to the temporary fencing using at least 2 temporary fencing clamps.
Temporary fence as the name suggests is a free standing, self-supporting fence panel, the panels are held together with clamps that interlock panels together making it portable and flexible for a wide range of applications. Fence panels are supported with counter-weighted feet, have a wide variety of accessories including gates, handrails, feet and bracing depending on the application. Fence panels are commonly constructed of either chain link or weld mesh.
Specifications
Fence panel height * width |
2.1*2.4m, 1.8*2.4m, 2.1*2.9m, 1.8*2.2m, etc |
||
Wire diameter |
3mm, 3.5mm, 4mm |
||
Mesh |
mostly welded wire mesh, chain link mesh is also available |
||
Mesh size |
60x150mm, 50x75mm, 50x100mm, 50x50mm, 60x60mm, etc. |
||
Frame tube O.D |
32mm, 42mm, 48mm, 60mm, etc. |
||
Panel material and surface |
hot dipped galvanized carbon steel |
||
Zinc mass |
42 microns or 17 microns |
||
Fence base/feet |
plastic feet filled with concrete (or water) |
||
Accessory |
Clamp, 75/80/100mm center space |
||
Optional parts |
extra brace, PE board, shade cloth, fence gate, etc. |
Application
The temporary fencing panels we supply are designed to withstand the test of time and the harsh conditions experienced on every building site. The quality is such that we now use the same specification panel in our hire business.
Temporary fence is an alternative to its permanent counterpart when a fence is required on an interim basis when needed for storage, public safety or security, crowd control, or theft deterrence.
It is also known as construction hoarding when used at construction sites. Other uses for temporary fencing include venue division at large events and public restriction on industrial construction sites.
Feature
Anti –climb mesh infill
360 weld between the vertical & horizontal pipe
Above average thickness of galvanising
Crimped ends on horizontal bars for extra strength
• Quickly and easy installation and removable
• weight heavyer
• Recycle
• Different options on color according to the using environment
The surface can do there types :1) hot dip galvanized after welded the zinc coating can reach 400g/m2 2) pre-galvanized wire and tube welded,zinc coating can reach 40-60g/m2 3) pre-galvanized wire and tube welded then PVC coating. Many RAL colors for your reference
Different blocks:1) injection molding 2) blow molding 3)steel plate
Australia Style Temporary Fencing production process
Packing terms
1)In bulk for full container;
2)By steel belt
3)OEM packing
Quality Control Process
Firstly, raw material test the Zn/Ai
Secondly, Semi-finished product test the size and quality
Then, finished Product’s Test the surface adhesive force (usually the post surface test )
Finally, finished Product’s installation
