Galvanized Steel Woven Wire Hinge Joint Fencing Farm Fence
Livestock Fence Panels
Farm fence, firm, smooth surface, even opening, good integrity.The product has good flexibility;Good resistance to pressure, corrosion and weather, can be used for a long time.Unlike electric welding grid, where solder joints are easy to break, our grass fence is always strong once installed and is the best material for protecting grassland, animals, forestry, highways and the environment.
Woven field fence Specifications
| No. | type | Specification | Weight (kg) |
Top and bottom wire Dia. (mm) | Body wire (mm) |
| 1 | 7/150/813/50 | 102+114+127+140+152+178 | 19.3 | 2.5 | 2.0 |
| 2 | 8/150/813/50 | 89(75)+89+102+114+127+140+152 | 20.8 | 2.5 | 2.0 |
| 3 | 8/150/902/50 | 89+102+114+127+140+152+178 | 21.6 | 2.5 | 2.0 |
| 4 | 8/150/1016/50 | 102+114+127+140+152+178+203 | 22.6 | 2.5 | 2.2 |
| 5 | 8/150/1143/50 | 114+127+140+152+178+203+229 | 23.6 | 2.5 | 2.0 |
| 6 | 9/150/991/50 | 89(75)+89+102+114+127+140+152+178 | 23.9 | 2.5 | 2.0 |
| 7 | 9/150/1245/50 | 102+114+127+140+152+178+203+229 | 26.0 | 2.5 | 2.0 |
| 8 | 10/150/1194/50 | 89(75)+89+102+114+127+140+152+178+203 | 27.3 | 2.5 | 2.0 |
| 9 | 10/150/1334/50 | 89+102+114+127+140+152+178+203+229 | 28.4 | 2.5 | 2.0 |
| 10 | 11/150/1422/50 | 89(75)+89+102+114+127+140+152+178+203+229 | 30.8 | 2.5 | 2.0 |
| Note: The first data in type is the No.of line wire; The second data is horizontal hole size(mm); The third data is the height of the fence(mm); The fourth data is the total length of the fence(mm). | |||||
Application
It is easy to use the planning of grassland resources, effectively improve grassland utilization and grazing efficiency, prevent grassland degradation and protect the natural environment. They are also applicable to agriculture, herd residents to establish family farms in the establishment of the border, farmland circle bar, forest nursery, afforestation enclosure, tourist area and hunting area, construction site isolation and maintenance.
Feature
Livestock panels are ideal for use in a number of applications around the farm or ranch, from cattle systems to round pens, from arenas to corrals, these panels are a solid choice anywhere confinement is needed.
The surface can do there types :1) hot dip galvanized after welded the zinc coating can reach 200g/m2
Produce process
Purchase the raw material wire--Zn/Ai coating test--woven--packing--Loading
Packing terms
packing with the pallet (steel pallet or wooden pallet)
