Hot Dip Galvanized Welded 4.0mm Dia Brc Mesh Fencing

50sets
MOQ
Negotiable
Price
Hot Dip Galvanized Welded 4.0mm Dia Brc Mesh Fencing
Features Gallery Product Description Request A Quote
Features
Specifications
Name: Welded Wire Garden Fence
Material: Metal
Wire Diameter: 4.0/4.5/5.0mm
Opening Size: 50*100-100*300mm
Length: 2.0-2.8m
Height: 830-2030mm
Color: Green/grey/brown/black/white
Surface 1: 1. Hot Dip Galvanized After Welded
Surface 2: 2. Powder Coating After Galvanized Wire
Surface 3: 3.PE Coated After Galvanized Wire
High Light:

welded brc mesh fencing

,

4.0mm dia brc mesh fencing

,

dia 4.0mm brc fencing

Basic Infomation
Place of Origin: China
Brand Name: Giant Fence
Certification: ISO9001:2001
Model Number: GF090
Payment & Shipping Terms
Packaging Details: 1. panels packing with pallet post bulk in the container 2. panel with post all bulk in the container 3. panle with post all packing with pallet
Delivery Time: 15-18days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000meters per month
Product Description

Outdoor Garden Powder Coated Specification Galvanized BRC Welded Mesh Fence





Roll Top Fence Introduction



BRC Fence is a mesh fence system that has a roll top to enhance the safety and rigidity of ence system. The roll top mesh fence system is most friendly system for install workers due to there are no any burrs or sharp, raw edges in the whole sheet of mesh fence.



Roll Top Fence Specifications



BRC Fence has attractive appearance, various colors, it not only has the fencing function but also has the beautify and safety effect.



Wire Dia. Mesh Size Length Height Round Post Size Common Color

4.0mm



5.0mm



6.0mm

50*100mm

50*150mm

50*200mm

75*200mm

100*200mm

100*300mm

2000mm



2200mm



2500mm



3000mm

1030mm

48*1.5/2.0mm



60*1.5/2.0mm

Green RAL6005
1230mm Black RAL9005
1530mm White RAL9010
1830mm Grey RAL7030
2030mm Red RAL3020
2230mm Yellow RAL1023
2430mm Blue RAL5017



Roll Top Fence Details of the post



Post view Size Thickness Panel height Base post Normal post Surface treatment
Square post

40x40mm

50x50mm

60x60mm

1.5mm

1.8mm

2mm

2.5mm

830mm 850mm 1200mm

1.Black tube Hot-dipped galvanized

2.Galvanized tube PVC coated

1030mm 1050mm 1400mm
1230mm 1250mm 1600mm

Round post



Φ48mm

Φ60mm

Φ75mm

1530mm 1550mm 2000mm
1830mm / 2400mm
2030mm / 2500mm



Roll Top Fence Material



1  iron wire (no zinc)

2  electro galvanized wire (zinc thickness: 10-20g/m2)

3  hot dipped galvanized wire (zinc thickness: 30-40g/m2)

4  heavy hot dipped galvanized wire (zinc thickness: 200g/m2)

5  Powder spray coated (thickness 0.1mm)

6  PVC/PE dipped coating (thickness 0.8-1.2mm)



Roll Top Fence Advantages



1 > With the characteristics of high strength, good rigidity, beautiful appearance, a broad field of vision, easy installation, bright feeling, light and practical.

2 > It is very compact connecting the mesh with the posts is very compact, whole feels good.

3 > Fluctuate of circle so that the net surface strength increased significantly.



Roll Top Fence Drawing of the fence




Roll Top Fence Packing



Hot Dip Galvanized Welded 4.0mm Dia Brc Mesh Fencing 1
