Factory Supply Powder Coated Building Construction Safety Edge Fall Protection Barrier Fence
Edge Protection Barriers
The unique characteristics of the perimeter barrier make it a market leader, as these ingenious barriers combine guardrails, baseboards and debris nets into a single, thin steel mesh barrier. A light-duty edge protection barrier made of steel and designed to provide perimeter edge protection for excavation. The system is designed for two-person installation and has different panel lengths to improve flexibility.
Specification Of Edge Protection Barriers
1.wire dia:5mm*4mm;6mm*5mm;8mm*6mm
2.mesh size:75*75mm;50*100mm;50*200mm;75*150mm
3.length:1.5m;2.0m;2.5m;3.0m
4.height:1.2m;1.3m;1.4m;1.5m
5.bending degree:60°/90°/12°
6.post:round post-48*2mm/60*2mm
square post-50*50*2mm/60*60*2mm
Advantages of Edge Protection Barriers
1.reinforced side bar for durability
2.returns no sharp edges on the top edge
3. Close and return to the kickboard for better debris control
4. Steel mesh protection with impact absorption capacity
Application Of Edge Ptotection Barriers
The edge protection fence is also called the edge protection fence. The edge protection is fully used in the construction under the building to protect people. Easy-to-install steel edge-protected barrier with impact-absorbing capacity, welds to withstand 500 kg of force, and complete debris-blocking Plinth. Suitable for live edge protection; plate edge protection; debris protection barrier; Steel Structure Protection; Safety Field Aisle. The Edge Protection System integrates into the manufacturing process by placing the integrated connections in the structural frame to accommodate the column assemblies that support the Wire Mesh Guardrail. The edge protectors are secured to the siding or from MEWP and, once installed, provide a continuous guardrail system for continuous-story high lifts, greatly reducing the risk of the installer falling from a height.
