| Place of Origin: | Hebei. China |
| Brand Name: | Giant Fence |
| Certification: | ISO14001:2015/OHSAS 18001:2007/ ISO9001:2015 |
| Model Number: | GF082 |
Powder Coating Anti Climb High Security Wire Airport Security Fencing
Airport Security Fencing Description
The airport fence is made of accessories such as low carbon steel wire welded plate column barbed wire or razor wire.It is a new type of fence specially designed for airports.
Airport Security Fencing Specification
We have three types of Airport Security Fence:
1. Triangle mesh panel:
2. Chain link mesh panel:
3. 358 mesh panel:
| Specification Of Airport Fence | |||||
| Mesh panel type | Panel height | Panel Width | Mesh size | Wire diameter | Post |
| Triangle mesh panel | 2.0-3.0m | 2.5m |
50*200mm 50*100mm 75*150mm |
3.0-6.0mm |
60*60mm 80*80mm 100*100mm |
| Chain link mesh panel |
2.0m*15m 2.4m*15m 3.0m*15m Distance of post:2.5-3.0m |
50*50mm 60*60mm 80*80mm |
3.0-6.0mm |
48mmOD 60mmOD |
|
| 358 mesh panel | 2.0-3.0m | 2.5m | 76.2*12.7mm (3’’*0.5’’) | 3.0-6.0mm |
60*60mm 80*80mm 100*100mm |
| Razor wire type | Razor wire diameter | ||||
| BTO-10; BTO-12; BTO-18; BTO-22; BTO-28; BTO-30; CBT-60; CBT-65 | 450mm,500mm,600mm,700mm,900m,960mm | ||||
| Above are general specification,others are available. | |||||
Airport Fence Application
Designed to provide attractive, durable and secure perimeter protection for retail, industrial and commercial properties, schools and public utilities, airport fencing is ideal for electronic alarm and detection systems, military, airports, security units and prisons.
Packing terms
Pack all bulk cargoes in containers
Pallet panels (steel or wood) after packing using bubble wrap bulk containers
Secure all packages in the container with pallets
All the clips and bottle caps are packed in cartons
