| Place of Origin: | China |
| Brand Name: | Giant fence |
| Certification: | ISO9001:2008 |
| Model Number: | GF139 |
Livestock Fence Livestock Farm Fence Cattle Fence Panels
Cattle fence panels
Heavy duty horse fence panel is made of welded hot dip galvanized pipes and wire for the use of fencing livestocks ,such as cattle,cow,bull,calves,dairy sheep,goat,hog.
Specifications of the panels
a. Square Style Cattle Fence -- Popular for Horse:
| Height x Length | 1.8 x 2.1m ( 6 rails ); 1.6 x 2.1m ( 5 rails ); 1.8 x 3.37m |
| Vertical Pipe | 40 x 40 x 1.6 /2.0mm; 50 x 50 x 1.6 /2.0mm |
| Horizontal Pipe | 40 x 40 x 1.6 /2.0mm; 50 x 50 x 1.6 /2.0mm |
| Customer requests can be reached. | |
b. Oval Style Cattle Fence -- Popular for Cow:
| Height x Length | 1.8 x 2.1m ( 6 rails ); 1.6 x 2.1m ( 5 rails ); 1.8 x 3.37m |
| Vertical Pipe | 40 x 40 x 1.6 /2.0mm; 50 x 50 x 1.6 /2.0mm square pipes |
| Horizontal Pipe | 30 x 60 x 1.6 /2.0mm; 40 x 80 x 1.6 /2.0mm oval rails |
| Customer requests can be reached. | |
c. Round Style Cattle Fence -- Popular for Horse:
| Height x Length | 1.8 x 2.1m ( 6 rails ); 1.6 x 2.1m ( 5 rails ); 1.8 x 3.37m |
| Vertical Pipe | 32mm OD x 1.6 /2.0mm; 42mm OD x 1.6 /2.0mm |
| Horizontal Pipe | 32mm OD x 1.6 /2.0mm; 42mm OD x 1.6 /2.0mm |
| Customer requests can be reached. | |
Feature
1.Portable: easy fast to handle (set up, remove and put down), makes the fence panel very flexible.
2.Robust: interlocking system makes the fence very stable; quality steel and
fully welding makes the panel more stronger; heavy duty and anti-broken; high zinc or PVC coated make the fence durable.
3.Environment Protection: connection with welded to bracket lugs and joining pins, no need to dig holes or lay foundations.And it benefit grassland protection.
4.Livestock Protection: no sharp edge, very smooth welding spot finishment
5.Cost-effective: give your corral years of service and minimal maintenance at a low initial cost.
Packing terms
1. Panel all packing with the pallet (steel pallet or wooden pallet)
2. Clips packing in the carton box
