Coated Flood Stone Gabion Cages Galvanized Gabion
Gabion Details
Gabion are rectangular baskets made of heavily galvanized, double twisted, steel woven wire mesh.
The single unit constructed baskets are assembled, laced together and then filled with stone to form a monolithic structure.
Gabions and es are used for retaining walls, sound barriers, channel linings, slope stabilization, dams and weirs.
They are particularly effective in restoring the environment and promoting vegetation growth.
Features
1. Soft structure
Exactly adapt to any changing of slope but not ruined by it, which more stable than rigid structure.
2. Strong capacity of Anti-scour
Even reach to 6m/s.
3. The structure has permeability essentially
Which let ground water leak while Precipitate suspended matter,mud to stay in the stone gaps, thus plants grow, restoring previous ecology.
Gabion material:
1. Hot dipped galvanized wire
2. Hot dipped galvanized wire+pvc
3. Galfan coating(5%AL+95%ZN)/+pvc coating
4. Super galfan coating()10%AL+90%ZN)/+pvc coating
Gabion Specifications:
| Materials | Mesh wire | Selvage wire | Tie wire | Mesh size | Length | Diaphragm | Width | Height |
|
Galvanized wire Galfan wire PE/PVC coated wire |
1.8mm 2.0mm 2.2mm 2.4mm 2.7mm 3.0mm |
2.4mm 2.7mm 3.0mm 3.4mm 4.0mm |
2.0mm 2.2mm 2.4mm |
60x80mm 80x100mm 100x120mm |
1.0m 2.0m 3.0m 4.0m 5.0m 6.0m |
No 1 2 3 4 5 |
0.5m 1.0m 1.5m 2.0m 3.0m |
0.3m 0.5m 1.0m 1.5m |
| Extra tie wire: 2% weight of gabion box | ||||||||
Gabion Applications
Gabion can be used as protective fences around your properties or as a support on slopes or paths. Single stone baskets can be used in your garden to design different fences around fireplaces, as base constructions for garden benches or bars, or to surround and decorate ponds or plants. You can even use them as a decorative support for climbing plants. Metal mesh baskets are made of firm wire.
Packing:
1. carton box or on pallet or bundle on the pallet
2. according to customers' request.
Service
1: Product Service
Our products offer 10 YEARS GUARANTEE.
2: Product customization services
We can customize products according to your requirements, including design and drawing.
3: After-sales service
Our after-sales service start immediately after signing the contract.
1.No matter FOB or CIF the price term is we would try our best to find a lowest freight cost for customers' reference.
2.The third-party inspection always gets real and true data from us and we will send production photos to customers if there is no inspection from the third-party.
3.Do our best to help customer arrange the shipment and customs clearance.
4.Installation, maintenance and repair instructions with full information.
