Galvanized High Tensile Welded Mesh Gabion Hesco Barrier
Hesco Barriers Blast Wall Introduction
Defensive barrier, also named as defensive bastion, defense wall,sand cage, welded gabion box,etc. It is a prefabricated, multi-cellular system, made of zinc coated steel welded mesh and lined with non-woven geotextile.Units can be extended and joined using the provided joining pins. It is easy installed with using minimal manpower and commonly available equipment. After extended, it is filled into sand, stone,then defensive barrier like a defence wall or bunker, it is widely used for military fortification and flood control.
Hesco Barriers Blast Wall Specifications
| Techbical Specification for Barrier panel | |
|
Steel wire
|
0.1% carbon Max steel
|
|
Wire thickness
|
3.5mm-5.0mm
|
|
Wire tensile
|
500-800Mpa
|
|
Welding tensile
|
50-100%of wire tensile strength
|
|
Mesh size
|
76.2*76.2mm
|
|
Surface treatment
|
Zinc coating or Zinc-Alu coating 40-600g/sqm |
Hesco Barriers Blast Wall Feature
Low cost, easy installation
10-Year limited warranty
Galvanized steel components
Suitable to all kinds of surrounding
Fire proof
Packing terms
1. Panel all packing with the pallet (steel pallet or wooden pallet)
2. bulk in the container
