3D Curved Garden Fence V Mesh Security Fencing
Description
Specification
|
Line wire x Cross wire |
Hole Size | Panel Length | Panel Height | Bending No. | Common Color | Surface treatment |
|
4x4mm 4.5x4mm 4.5x4.5mm 5x4mm 5x5mm 6x5mm 6x6mm |
50X100mm 50X200mm 55X200mm 75X150mm 100X300mm
|
2m 2.2m 2.4m 2.5m 2.8m 3m |
830mm | 2 |
Green RAL6005 Grey RAL7016 Brown RAL8019 Black RAL9005 White RAL9010 |
1.Hot-dipped galvanized after black wire welded 2.PVC coated after galvanized wire welded 3.PE coated after galvanized wire welded |
Application
| Commercial grounds | Corporation, hotel, supermarket |
| Private grounds | Courtyard, Villadom |
| Public grounds | Park, zoo, train or bus station, lawn |
| Road and transit | Highway, railway or road city transit |
| Various facilities | industry,agriculture, transport, etc. |
Feature
Easy Installation
Cost effective
Durable, corrosion resistance, Galvanized wire then PVC coated
Different colors available according to customers’ special requirements. RAL 6005, 7016, etc
Different post available
Anti-climbing, high strength, strong protection ability
Specifications Of the Sqaure Post
| Post view | Size | Thickness | Panel height | Base post | Normal post | Surface treatment |
| Square post |
40*40mm 50*50mm 60*60mm |
1.0mm 1.1mm 1.2mm 1.5mm 1.8mm 2mm 2.5mm |
830mm | 850mm | 1200mm |
1.Black tube Hot-dipped galvanized 2.Galvanized tube PVC coated |
| 1030mm | 1050mm | 1400mm | ||||
| 1230mm | 1250mm | 1600mm | ||||
| 1530mm | 1550mm | 2000mm | ||||
| Rectangle post |
30*50mm 40*60mm 60*80mm |
1830mm | / | 2400mm | ||
| 2030mm | / | 2500mm | ||||
| 2230mm | / | 2800mm | ||||
| 2430mm | / | 3000mm |
