Twin Wire Steel Meshes Steel Fence 6/5/6 Double Wire special design fence
Double wire security fence panel Details
Double wire mesh fence is high quality low-carbon steel wire as materials. It have one vertical wire and two horizontal wires. It is stronger than normal welded wire mesh, wire diameter: 6/5/6mm, 8/6/8mm.
656mesh consists of double 6mm horizontal wires together with single 5mm vertical wires.
868mesh consists of double 8mm horizontal wires together with single 6mm vertical wires.
Advantage:
1. Vandal resistant, Low maintenance
2. Strong and reliable security
3. Simple structure, Attractive appearance
4. Easy installation, Convenient transport
Application: Fencing and protection for road, railway, airport, residence district, seaport, garden, feeding and husbandry.
Packaging
1>it has rubber mat at the bottom of the pallet to avoid the pallet destroyed the panel
2>it has 4 metal corners to keep the pallet more strong.
3>it has metal plate under the plastic bandage to reduce the pressure of fence panels.
4>it has wooden plate at the top of fence panel which can protect the fence panels avoid being crushed by other pallets
post:every post pack with a plastic bag(the cap is covered well on the post)+metal pallet
accessories:small plastic bag+carton box
Double wire security fence panel Specifications:
| Wire Diameter | Mesh Size | Panel Height(mm) | Panel Width(mm) | Post Height(mm) | Post Size |
|
8/6/8mm 6/5/6mm |
200*50mm | 630 | 2500 | 1100 |
40*40*1.5mm 40*60*2mm 60*60*2mm 80*80*2mm |
| 830 | 2500 | 1300 | |||
| 1030 | 2500 | 1500 | |||
| 1230 | 2500 | 1700 | |||
| 1430 | 2500 | 1900 | |||
| 1630 | 2500 | 2100 | |||
| 1830 | 2500/3000 | 2400 | |||
| 2030 | 2500/3000 | 2600 | |||
| 2230 | 2500/3000 | 2800 | |||
| 2430 | 2500/3000 | 3000 | |||
| Material | Low carbon steel wire,Galvanized wire,etc. | ||||
| Surface treatment | Hot dip galvanized,Powder coated,etc. | ||||
