Military Welded Mesh Gabion Hesco Barrier Blast Wall

50 sets
MOQ
Negotiable
Price
Military Welded Mesh Gabion Hesco Barrier Blast Wall
Features Gallery Product Description Request A Quote
Features
Specifications
Name: Hesco Barrier Welded Defensive Bastion
Material: Q195, Q235
Fabric Color: Brown/green
Wire Diameter: 4.0mm, 4.5mm, 5.0mm
Mesh Size: 76*76mm/75*150mm/100*100mm
Hole: Square
Surface: Galvanized Wire Welded/Galfan Wire Welded/hot Dip Galvanized After Welded
Packing: Wooden Pallet
Size: Mil 1B/1G To Mil 10B/10G
High Light:

gabion hesco barrier blast wall

,

welded mesh hesco barrier blast wall

,

military hesco barrier blast wall

Basic Infomation
Place of Origin: China
Brand Name: Giant Fence
Certification: ISO9001:2008
Model Number: HB---005
Payment & Shipping Terms
Packaging Details: 1. packing in the pallet 2. bulk in the container
Delivery Time: 20-25days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5000meter per week
Product Description

Military Welded Mesh Gabion Hesco Barrier Welded Defensive Bastion





Hesco Barriers Blast Wall Introduction




Hesco barrier also named as Hesco bastion, Hesco defense wall, sand cage, welded gabion box, etc.It is a prefabricated,multi-cellularsystem, made of zinc coated steel welded mesh and lined with non-woven geotextile. Units can be extended and joined using the providedjoining pins. It is easy installed with using minimal manpower and commonly available equipment. After extended,it is filled into sand,stone,then hesco barrier like a defence wall or bunker,it is widely used for military fortification and flood control.





Military Welded Mesh Gabion Hesco Barrier Blast Wall 0

Hesco Barriers Blast Wall Specifications



Unit Type

Height

( M )

Width

( M )

Length

( M )

Internal Cells
MIL 1 1.37 1.08 10 9
MIL 2 0.61 0.61 1.22 2
MIL 3 1.0 1.0 10 10
MIL 4 1.0 1.5 6 6
MIL 5 0.61 0.61 3.05 5
MIL 6 1.68 0.61 3.05 5
MIL 7 2.21 2.13 8.25 4
MIL 8 1.37 1.22 10 9
MIL 9 1.0 0.76 6.84 9
MIL 10 2.13 1.52 7.60 5



Military Welded Mesh Gabion Hesco Barrier Blast Wall 1



Hesco Barriers Applications



1.Perimeter security and defence walls

2.Equipment revetments
3.Ammunition compounds
4.Personnel and material bunkers
5.Obsercation points
6.Defensive firing positions
7.Entry control points
8.Guard posts
9.Explosives and contraband search areas
10.Highway checkpoints
11.Border crossing checkpoints
12.Protecting existing structures
13.Highway traffic management
14.Hostile Vehide Mltigation



Hesco Barriers Blast Wall Feature



1.smooth and tidy, uniform mesh, joints firm, the firm has a strong, corrosion resistance, etc.

2. low-cost, easy to install, decorate the courtyard, ideal for green slope.

3. a strong resistance to withstand natural weather damage and impacts.

4. very good anti-stretch capability.



Military Welded Mesh Gabion Hesco Barrier Blast Wall 2



Packing terms



1. Panel all packing with the pallet (steel pallet or wooden pallet)

2. bulk in the container



Military Welded Mesh Gabion Hesco Barrier Blast Wall 3
