Powder Coated 1.2m Height Customized Iron Wire Mesh Construction Building Reinforced Edges Protection Barrier
Edge Protection Barrier Introduction
Edge protection fence also named edge protection Barrier,Temporary edge protection,Safety Edge Barrier,edge protection is fully used in construction under building to protect people.
This simple to install system offers site personnel maximum protection on the perimeter of construction slabs, around stair and lift wells, excavations etc. The removable panels, with built-in kickplates, and post system is easily transported, installed removed and stored.
Specification Of Edge Protection Barrier
The 2600mm x 1200mm galvanised welded mesh panel are manufactured from 5mmand 8mm steel wire with centres not exceeding 300mm, complying with EN Standard.
Featuring 90 degree bending top and bottom, incorporating a galvanised kickplate that helps prevent objects falling through the panel bottom.
The edge protect barrier system is an ideal choice, easy and fast to install.
| Type of Edge Protection Barriers | |||
| Type | Type 1 | Type 2 | Type 3 |
| Weight | 9Kg | 16Kg | 18Kg |
| Length | 1500mm | 2000mm | 2500mm |
| Height | 1300mm | 1400mm | 1500mm |
| Finish | Gaiv. wire+Powder coat | ||
| Material | Metal | ||
| Wire diameter | 4.0*5.0mm/6*5mm/8*6mm | ||
| Mesh size | 75*75mm/50X100mm,50X200mm | ||
| Color | Red, yellow, bule, white, Support customization | ||
Advantages of Edge Protection Barrier
1. Reinfored side bars for enhanced durability
2. Returned top edge with no sharp edges
3. Closed and returned toeboard for greater debris containment
4. Steel mesh protection with impact-absorbing capacity
Feature Of Edge Protection Barrier
1. Made of international standard mild steel, it is strong and resistant to collision, and can withstand external shock of 1000N;
2. Strong welding, tough and stable, standardized design, quick and convenient installation;
3. Fully automatic high temperature paint, pure color, 3 years fast;
4. The double color scan line is eye-catching and beautiful, which helps enhance the image of the civilized construction site;
5. Can be reused to reduce user costs;
6. Product size and color can be customized to meet customer requirements;
7. Wide application scenarios, applicable to construction site maintenance, floor border protection, material yard separation, foundation pit border protection.
Application Of Edge Protection Barrier
Edge Protection Barrier Fence also named edge protection fence,edge protection is fully used in construction under building to protect people.
Easy to install steel edge protection barrier with impact-absorbing capacity, welds that can withstand a force of 500kg and full debris containment toe board.Suitable for Live edge protection; Slab edge protection; Debris guard barrier; Structural steelwork protection;Safe site walkway.
